Multi-Media Sand FIltration
Best Duplex Multimedia Water Filtration System

Multi Media Sand Water Filter System

Best Multi-Media Sand Filtration

Multi-Media Sand Filtration System With Full Automatic Control Valve From USA. Multi-Media filter consists of progressively finer layers of filter media including anthracite, sand, and garnet. As the supply water travels through the filter bed, the suspended solids are removed (from 10 – 15 micron in size) Aqua Best FRP multimedia sand filtration system commonly uses three layers of media for sight and sound filtration: anthracite, sand, and garnet. These media are frequently picked for use in insight and sound channels because of the particular contrasts in their densities. Anthracite is the lightest filtration media per unit volume, trailed by sand, and afterward garnet.

Multi-Media Sand Filtration System in Dubai, U.A.E.

Description:-

  • Model number: 13×54 – 16×65- 21×63 – 24×69 – 30×72 – 84×82
  • Mineral Tank Size (Inches): 13×54 – 1665- 21×63 – 24×69 – 30×72 – 84×82
  • Service Flow: 15- 21-39- 48 Up to 330 GPM
Category:

Description

Multi Media Sand Water Filter System in Dubai – Aqua Best

The Multi Media Sand Water Filter System is one of the most effective solutions for reducing suspended solids, turbidity, dirt, and impurities from water. Unlike conventional single-media sand filters, a multi-media filter uses several layers of different filtration materials such as anthracite, fine sand, garnet, and gravel. This layered design provides deeper filtration, higher dirt-holding capacity, and improved water clarity. At Aqua Best UAE, we supply and install multi-media sand water filter systems in Dubai, Abu Dhabi, Al Ain, and across the UAE for residential, commercial, and industrial applications.

Why Choose a Multi Media Sand Water Filter System?

  • Superior Filtration Efficiency – Removes particles as small as 10–20 microns.

  • Layered Filtration Technology – Multiple layers ensure more thorough and consistent water treatment.

  • Longer Media Life – Designed for 3–5 years of service before replacement.

  • Protects RO Systems – Acts as a pretreatment to extend membrane life in reverse osmosis plants.

  • Durable & Reliable – Available in FRP (Fiberglass Reinforced Plastic) or stainless steel vessels.

How the System Works

Water passes through multiple filtration layers:

  1. Anthracite Layer – Removes larger suspended solids.

  2. Fine Sand Layer – Captures medium-sized impurities and turbidity.

  3. Garnet Layer – Traps fine sediments and ensures uniform flow.

  4. Gravel Bed – Supports media layers and distributes water evenly.

The result is clear, clean water with reduced turbidity, ready for domestic use, industrial processes, or further treatment like RO or UV.

Technical Specifications

  • Flow Rates: From 2 m³/h to 500 m³/h (customizable)

  • Vessel Material: FRP or Stainless Steel 304/316

  • Operating Pressure: Up to 150 PSI

  • Valves: Manual multiport valve or Automatic backwash control valve

  • Backwashing: Automatic or manual cleaning to extend media life

  • Applications: Pre-treatment, cooling towers, boiler feed, irrigation, industrial processes

Applications in Dubai & UAE

  • Residential Villas & Communities – Provides safe, clean water for whole-house use.

  • Commercial Properties – Hotels, restaurants, cafés, and office buildings.

  • Industrial Use – Cooling towers, process water, and factory applications.

  • Municipal Water Supply – Improves quality in large-scale water treatment plants.

  • Agriculture & Irrigation – Protects crops and irrigation systems from suspended particles.

Benefits of Aqua Best Multi Media Sand Filters

  • Removes turbidity, dirt, and fine sediments.

  • Provides higher dirt-holding capacity than traditional sand filters.

  • Extends life of downstream equipment like RO membranes and UV systems.

  • Easy operation with fully automatic backwash options.

  • Supported by Aqua Best’s professional supply, installation, and AMC services in Dubai.

FAQs – Multi Media Sand Water Filter Systems

Q1: How often should the media be replaced?
👉 Every 3–5 years, depending on feedwater quality and usage.

Q2: What is the difference between a sand filter and a multi-media filter?
👉 A sand filter uses only sand, while a multi-media filter uses layered media for higher efficiency.

Q3: Can this system be used before an RO plant?
👉 Yes, it is one of the most common pretreatment stages for reverse osmosis systems.

Q4: Do you provide installation in Dubai?
👉 Yes, Aqua Best supplies, installs, and services multimedia sand filters across Dubai, Abu Dhabi, and the UAE.

Contact Aqua Best Dubai

Upgrade to a reliable Multi Media Sand Water Filter System in Dubai with Aqua Best. Designed for long-term performance, our systems are perfect for residential, commercial, and industrial applications.

📞 Call/WhatsApp: +971 52 992 0566
📍 Aqua Best – Dubai, UAE
